Positive Displacement Flow Meter
The Georgia Solutions Flow Meters is a high-accuracy positive displacement (PD) flow meter designed for reliable and consistent measurement of liquid flow rates in industrial and commercial applications. Its robust construction and precision-engineered internals ensure long-term performance even in demanding environments. NOT TO BE USED IN CUSTODY TRANSFER APPLICATIONS.
Configure Your Flow Meter
Select Flow Meter Model
Model Specifications
Select a model to see specifications
Compatible Accessories
No accessories selected
We'll email you a formal quote with lead time & shipping.
Features
- Consistent precision over time — the absence of metal-to-metal contact within the measuring chamber reduces wear, resulting in fewer recalibrations and an extended operational lifespan.
- NOT TO BE USED TO MEASURE LIQUID FOR RESALE.
- Accurate metering is maintained across a broad temperature spectrum, ranging from -40°F (-40°C) to 160°F (71°C).
Model Specifications
GSM-15 — $779.99 — 60 GPM max
| Flange Size | 1.5" |
|---|---|
| Flow Range | 7–60 GPM |
| Weight | 14 lbs |
| Max Pressure | 1450 PSI |
| Temperature Range | -40 to 160 |
| Accuracy | ±0.05% |
GSM-20 — $839.99 — 150 GPM max
| Flange Size | 2" |
|---|---|
| Flow Range | 15–150 GPM |
| Weight | 20 lbs |
| Max Pressure | 1450 PSI |
| Temperature Range | -40 to 160 |
| Accuracy | ±0.05% |
GSM-30 — $1899.99 — 300 GPM max
| Flange Size | 3" |
|---|---|
| Flow Range | 30–300 GPM |
| Weight | 30 lbs |
| Max Pressure | 1450 PSI |
| Temperature Range | -40 to 160 |
| Accuracy | ±0.05% |
GSM-40 — $3239.99 — 450 GPM max
| Flange Size | 4" |
|---|---|
| Flow Range | 45–450 GPM |
| Weight | 40 lbs |
| Max Pressure | 1450 PSI |
| Temperature Range | -40 to 160 |
| Accuracy | ±0.05% |
Why Georgia Solutions Flow Meters?
Georgia Solutions Positive Displacement (PD) Flow Meters offer unmatched value for operations that demand precision, durability, and compatibility. Engineered to perform on par with industry leaders like Liquid Controls® (LC) and Total Control Systems® (TCS), our PD meters deliver the similar quality and reliability at a significantly lower cost.
Whether you're outfitting a new system or replacing parts in an existing LC or TCS setup, our meters and spare parts fit seamlessly. No compromises, no costly conversions.
| Flange Size | Max. Capacity | Georgia Solutions | Liquid Controls® | Total Controls Systems® |
|---|---|---|---|---|
| 1 ½" | 60 GPM | GSM-15 | M-5® | 700-15 |
| 2" | 100 GPM | GSM-20 | M-7® | 700-20 |
| 2" | 150 GPM | GSM-20 | M-10® | 700-25 |
| 3" | 200 GPM | GSM-30 | M-15® | 700-30 |
| 3" | 300 GPM | GSM-30 | N/A | 700-35 |
| 4" | 350 GPM | GSM-40 | M-25® | N/A |
| 4" | 450 GPM | GSM-40 | M-40® | 700-40 |
Brand names and model numbers are used for compatibility reference only. Georgia Solutions is not affiliated with or endorsed by Liquid Controls® and Total Controls Systems®.
Two Tracks, One Meter Family
INDUSTRIAL · IN STOCK
🏭 Industrial Process Control
From $779.99
- ✅ Available now — in stock
- ✅ ±0.05% accuracy (factory calibrated)
- ✅ Internal fuel tracking, blending, inventory
- ✅ Aviation FBO, lube plants, terminals (non-custody)
- ⚠️ NOT for custody transfer / legal-for-trade
NTEP PENDING · 2026
⚖️ Custody Transfer (NTEP)
Coming 2026
- ⏳ NTEP evaluation in progress
- ⏳ Legal for trade (retail, billing, resale)
- ⏳ HB44 compliant, state-approved
- 📧 Join waitlist
• Lower Cost
Significant savings compared to name-brand systems• Focus on Quality
Manufactured to meet or exceed industry standardsBuilt to Industry Standards
⚙️ Factory Calibrated ±0.05%
🌡️ -40°F to 160°F Operating Range
🔧 LC/TCS Interchangeable
📋 1-Year Warranty
📦 30–60 Day Lead Time
Certification Progress
✓
Design Complete
✓
Prototype Testing
🔬
Pre-NTEP Validation
3
NTEP Submission
4
Certificate of Conformance
Target: NTEP CC by Q2 2027. Request timeline details →
Make the switch to Georgia Solutions and get the performance you need with the budget you want.
